Roller Assembly for HR1500H

This is the complete roller assembly for the Pioneer HR1500 H Automatic Covering System. Product weight 180 lbs.
HR1515-1 Parts Incude:
121HHSMS: #12 x 1in HHSMS (Qty: 2)
38165HHCS5: 3/8 x 1/2in HHCS Gr. 5 (Qty: 1)
38165RHMS: 3/8-16 x 1/2in RHMS (Qty: 12)
381675HHCS5: 3/8-16 x 3/4in HHCS Gr. 5 (Qty: 10)
516181HHCS5: 5/16-18 x 1" Hex Head Bolt (Qty: 2)
5161875HHCSSS: 5/16-18 x 3/4in HHCS (SS) (Qty: 3)
51618SLN: 5/16-18in Stoverlock Nut (Qty: 1)
516FWSAE: 5/16 SAE Flat Washer (Qty: 2)
516LWSS: 5/16in Lock Washer (SS) (Qty: 3)
EDD1503: Bearing for Roll - R.S. (Qty: 1)
G1633: Center Section, Alum Roll (Qty: 1)
G1641: Roll & Plug Assy, L.S. w/ X Ho (Qty: 1)
G1643: Roller, Alum w/ 1in Plug, Shaf (Qty: 1)
H7032: Clevis Eye Pad (Qty: 1)
HR1508: Hydraulic Motor, Gear Box Assy (Qty: 1)
HR1514: Mtg Plate, HR1500 (Qty: 2)
HR4503: Windscreen (Qty: 1)
HR4504B: Windscreen Support Angle, 5 7/ (Qty: 2)
HR4505: Roll, Base Only (Qty: 1)
HR4571: Windscreen Mtg. Angle - Truck (Qty: 1)
K0355: 3/8" Nut (Qty: 24)
K0365B: 5/16 Lock Washer (Qty: 2)
K0383: 3/8" x 1" Hex Head Bolt (Qty: 4)
K0391: 5/16 x 2 1/2 Hex Head Gr. 8 (Qty: 1)
R0158: 5/16 Nut (Qty: 2)
R0163: 3/8 Lock Washer (Qty: 15)
WSDTT: DECAL - Windscreen - inTuff-Ta (Qty: 1)
