Hydro Over Electric Gantry

A quick and easy solution for quickly and safely securing loads, the HR0500 hydro over electric gantry from Pioneer is a true timesaver. The HR0500 is a fixed system with # available positions/fully adjustable and ideal for a wide variety of dump truck trailers with roll-off container systems. The truck’s hydraulic system in tandem with a compact motor to smoothly wind/unwind the tarp and extends vertically from #” to #” inches. A quality design yields lower maintenance for years of dependable performance. HR0500 Parts Include:
1420325HHCS5: 1/4-20 x 3-1/4 HHCS GR5 (Qty: 1)
14STOVERLCKN: 1/4-20 Stoverlock Nut (Qty: 1)
381650HHCS5: 3/8-16 x 5 HHCS GR5 (Qty: 4)
381675HHCS5: 3/8-16 x 3/4in HHCS Gr. 5 (Qty: 2)
H7032: Clevis Eye Pad (Qty: 1)
H7048: 3/8 NPTM x -6 JICM 90 Deg. Ell (Qty: 2)
H7062: Clevis Pin w/ Cotter (Qty: 2)
HR2081: Pump Mount, Gantry (Qty: 1)
HR2084: Clamp, Gantry Pump Mount (Qty: 2)
HR2088: Double Acting Power Unit, 2Gal (Qty: 1)
HR2090: Pendant Mount, 2 Button (Qty: 1)
HR4505: Roll, Base Only (Qty: 1)
HR4511: Gantry Assy, COMP w/Legs & Eye (Qty: 1)
HR4520: Gantry Cylinder - 36" Stroke (Qty: 1)
HR4553: 1/4 NPTx-6 JIC 90 Deg. ELL (Qty: 1)
HR4562A: Hydraulic Hose, -4 x 9ft L -06 (Qty: 1)
HR4563: Hydraulic Hose, -4 x 6ft L -06 (Qty: 1)
K0353: 3/8" Flat Washer (Qty: 2)
K0355: 3/8" Nut (Qty: 8)
R0163: 3/8 Lock Washer (Qty: 6)
ROT0129: Circut Brkr. ROT 150 Amp (Qty: 1)
RTE5756: Ring Terminal, 5/16 x 6 Ga (Qty: 4)
